Product may vary slightly from the item pictured due to model upgrades.
Read all instructions carefully before using this product.
Retain this owner's manual for future reference.
NOTE:
This manual may be subject to updates or changes. Up to date manuals are available through our
website at www.lifespanfitness.com.au
Pursuit 3
Treadmill
USER MANUAL
Advertisement
Table of Contents
Related Manuals for LifeSpan Pursuit 3
Summary of Contents for LifeSpan Pursuit 3
- Page 1 Pursuit 3 Treadmill USER MANUAL Product may vary slightly from the item pictured due to model upgrades. Read all instructions carefully before using this product. Retain this owner’s manual for future reference. NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions ....... 03 II. Important Electrical Information ......05 III. -
Page 3: Important Safety Instructions
I. IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all instructions before using this treadmill. It is important your treadmill receives regular maintenance to prolong its useful life. Failing to regularly maintain your treadmill may void your warranty. DANGER To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to cleaning and/or service work. - Page 4 • The treadmill is intended for in-home use only and is not suitable for commercial environments. • To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug from the outlet. • The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings.
-
Page 5: Important Electrical Information
II. IMPORTANT ELECTRICAL INFORMATION WARNING! • Route the power cord away from any moving part of the treadmill including the elevation mechanism and transport wheels. • NEVER remove any cover without first disconnecting AC power. • NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors, near a pool, or in any other high humidity environment. -
Page 6: Important Operating Instructions
III. IMPORTANT OPERATING INSTRUCTIONS • Understand that changes in speed and incline do not occur immediately. Set your desired speed on the display console and release the adjustment key. The display will obey the command gradually. • Use caution while participating in other activities while walking on your treadmill, such as watching television, reading, etc. -
Page 7: Assembly Instructions
IV. ASSEMBLY INSTRUCTIONS PARTS LIST Description Specification Description Specification Main Frame Silicone Oil 5#Allen Wrench Safety Key Bolt M8*42 Bolt M8*16 Lock Washer Power Wire FIXING TOOLS: 5# Allen Wrench 5mm 1PC Wrench with screwdriver S=13/14/15 1PC NOTICE: Do not turn on machine until assembly is completed. ASSEMBLY INSTRUCTIONS |... - Page 8 STEP 1 STEP 2 1. Open the carton, take out the above parts. 1. Hold the upright arms and use the 5# Allen 2. Put the Main Frame on the level ground. wrench to secure bolt (56) and lock washer (67) through the hole on the left upright and base frame (as pictured).
- Page 9 STEP 3 STEP 4 1. Fasten the left & right-side decorative cover CAUTION: (27) on the handlebar. There is cables leading from the display 2. Turn the computer (6) to a suitable angle. and the upright arms. Be careful when unfolding it to avoid cutting the cables.
-
Page 10: Folding Instructions
V. FOLDING INSTRUCTIONS FOLDING Pull up the base frame at position A, until you hear the sound that the air pressure bar B is locked into the round tube. UNFOLDING Support place A with hand, tap on the place of air pressure bar, then the main frame will slowing come down automatically. -
Page 11: Operation Guide
VI. OPERATION GUIDE OVERVIEW 1. WINDOW DISPLAY SPEED: Display the speed. TIME: Display the time. DIST: Display the distance. CAL: Display the calories. PULSE: Display the heart rate. OPERATION GUIDE |... - Page 12 3. KEY FUNCTION "START" Button: Press this button to start the machine, the machine will run at the lowest speed or at the speed of default program. "STOP" Button: Pause/stop key. In the running state of the treadmill, press this key to pause the treadmill.
- Page 13 4. HEART RATE SENSOR When holding the hand pulse by two hands, the pulse window will show your heartrate after 5 seconds. In order to get the heartrate more correct, please test when the machine is stopped, and holding the hand pulse more than 30 seconds.
- Page 14 7. SAFETY KEY FUNCTION Click the safety key to your clothing. If you are going too fast, pull the cord and the key will come off from display. This will stop the treadmill. All the windows will display "------". The key must be fitted back into place to start the treadmill again.
-
Page 15: Exercise Guide
VII. EXERCISE GUIDE PLEASE NOTE: Before beginning any exercise program, consult your physician. This is important especially if you are over the age of 45 or individuals with pre-existing health problems. The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings. - Page 16 COOL DOWN Finish each workout with a light jog or walk for at least 1 minute. Then complete 5 to 10 minutes of stretching to cool down. This will increase the flexibility of your muscles and will help prevent post- exercise problems.
-
Page 17: Maintenance Instructions
VIII. MAINTENANCE INSTRUCTIONS Reasonable cleaning/lubricating should be made to extend the life time of this unit. Performance is maximized when the belt and mat are kept as clean as possible. WARNING: • The mat/deck friction may lay a major role in the function and life of your treadmill and that is why we recommend you constantly lubricate this friction point to prolong the useful life of your treadmill. - Page 18 Running Belt Board Video Tutorial Available at: http://youtu.be/cP9NtFHfWlc Lifespan Fitness YouTube Channel: http://www.youtube.com/user/treadmillsvideos 4. HOW TO CHECK THE RUNNING MAT FOR PROPER LUBRICATION 1. Disconnect the main power supply. 2. Fold the treadmill up into the storage position. 3. Feel the underside surface of the running mat.
- Page 19 5. ADJUSTING THE RUNNING BELT Place treadmill on a level surface. Run treadmill at approximately 4km/h, checking the running condition. If the belt has drifted to the right: Whilst the If the belt has drifted to the left: Whilst the treadmill is running at 4km/h, carefully turn treadmill is running at 4km/h, carefully turn the right adjusting bolt 1/4 turn clockwise.
- Page 20 Some treadmills that have longer belts may give different measurements for correct belt tightness. Simply, if the belt begins to slip during use, this is an indication that the belt still needs tightening. Video Tutorial Available at: http://youtu.be/vllsamTSvvA Lifespan Fitness YouTube Channel: http://www.youtube.com/user/treadmillsvideos 20| MAINTENANCE INSTRUCTIONS...
-
Page 21: Replacing Motor Brushes
IX. REPLACING MOTOR BRUSHES After extended use, the motor brushes in your treadmill motor will wear down, and this can lead to motor failure. It is important that you maintain your motor by replacing the brushes on either side of the motor when they are worn down. - Page 22 4b. Some treadmill motors may use a push 4c. Remove the clip, noting the direction in clip instead. In this case, gently push the which it was originally placed, and put it clip inwards and then up to release it from safely aside.
- Page 23 9a. Release the clip back into its position. 9b. If your motor uses a push clip, replace the push clip by pushing it inwards and then down so that it engages the catch. 10. Check that the motor brush is held firmly 11.
-
Page 24: Exploded Diagram
X. EXPLODED DIAGRAM | EXPLODED DIAGRAM... -
Page 25: Parts List
XI. PARTS LIST Description Specs Description Specs Tile Main Frame Wheel Cover Base Frame Left Upright Foot Pad Right Upright Transportation Wheel Computer Bracket Left Side Rail Adapter Block Rotating Shaft Tube Safety Key Cylinder Silicon Oil 5# Allen Wrench Control Board Fix Pin Hand Pulse with... -
Page 26: Trouble Shooting Guide
Description Specs Description Specs Screw Screw M6*60 4.2*12 Screw Lock Washer 4.2*13 Screw M8*45 Screw 4.2*12 Lock Washer Screw 4.2*9 Lock Washer Screw 2.9*8 Drive Belt Standard Spring Washer Motor Fixing Plate Lock Washer Standard Spring Washer Reinforced Rod Cushion Lock Washer Elastic Cushion Screw... - Page 27 Code Reason Solution Motor open-phase protection 1. Check whether the motor wiring is normal, if it is normal, replace the control board 2. Change the motor. Motor lock-up protection 1. It is overload, or the motor/ rollers are stuck. Check whether the transmission parts are normal.
-
Page 28: Warranty
Any claim against this warranty must be made through your original place of purchase. Proof of purchase is required before a warranty claim may be processed. If you have purchased this product from the Official Lifespan Fitness website, please visit https://lifespanfitness.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit https://lifespanfitness.com.au/warranty-form and fill in our Repair/Service... -
Page 29: Hand Pulse Technology
XIV. HAND PULSE TECHNOLOGY This product comes equipped with hand pulse sensors which are used to pick up tiny EKG/ECG signals that run through the body when your heart beats. These electrical EKG/ECG signals are very small and must be amplified 1000 times to make the signal viable for the computer to display your pulse. To ensure proper operation: •... - Page 32 WWW.LIFESPA NF ITN ES S.COM.AU...
