- Page 1 AccuBoom™ Installation Manual Miller Condor G-Series...
- Page 2 GPS satellites, the OmniSTAR correction service or the WAAS correction service. Raven Industries accepts no responsibility for the use of the signal for other than the stated purpose. Raven Industries shall not be responsible or liable for incidental or consequential damages or a loss of anticipated benefits or profits, work stoppage or loss or impairment of data arising out of the use, or inability to use, the SmarTrax or any of its components.
-
Page 3: Table Of Contents
Point of Reference ....................... 4 AccuBoom Kit Contents ......................5 Chapter 3 AccuBoom Installation............7 Install the AccuBoom Node ....................... 7 Install the AccuBoom Harness Cable ..................8 Chapter 4 Section Mapping Setup ............11 Envizio Pro ..........................11 Viper Pro .......................... - Page 4 Table of Contents Miller Condor G-Series AccuBoom Installation Manual...
-
Page 5: Important Safety Information
Raven dealer for support. • Follow all safety labels affixed to the AccuBoom system components. Be sure to keep safety labels in good condition and replace any missing or damaged labels. To obtain replacements for missing or damaged safety labels, contact your local Raven dealer. - Page 6 Chapter 1 Miller Condor G-Series AccuBoom Installation Manual...
-
Page 7: Chapter 2 Introduction
C h a p t e r 2 Introduction Congratulations on your purchase of the Raven AccuBoom system! This system is designed to provide accurate and cost-efficient application control by avoiding no-spray zones and eliminating wasteful overlaps. This manual applies to the following machines. For future reference, write your serial number in the space below. -
Page 8: Recommendations
Set of tools Preparing for Installation Before installing AccuBoom, park the machine where the ground is level, clean, and dry. Leave the machine turned off for the duration of the installation process. During the installation process, follow good safety practices. Be sure to carefully read the instructions in this manual as you complete the installation process. -
Page 9: Accuboom Kit Contents
Introduction AccuBoom Kit Contents This section contains a list of the components that are included in the AccuBoom kit. Before beginning the AccuBoom installation, compare the items in the AccuBoom kit with the components on this list. If you have questions about the kit, contact your local Raven dealer. - Page 10 Chapter 2 Miller Condor G-Series AccuBoom Installation Manual...
-
Page 11: Accuboom Installation
C h a p t e r 3 Installation The instructions in this manual are designed to assist in the proper installation of the AccuBoom system on Miller Condor G-Series sprayers. Refer to your computer’s Installation & Operation Manual for instructions on setting up the software and using the AccuBoom system. -
Page 12: Install The Accuboom Harness Cable
Locate the 12-pin Deutsch connectors labeled CD04 and CD05 connected together on the chassis harness cable. Disconnect the connectors. AccuBoom Harness Connected to the Machine’s Harness FIGURE 3. Install the Miller Condor G-series CAN AccuBoom cable (P/N 115-1001-042) between the CD04 and CD05 connectors. Miller Condor G-Series AccuBoom Installation Manual... - Page 13 AccuBoom Installation AccuBoom Node Installed FIGURE 4. Insert the large, rectangular node connectors on the cable (P/N 115-1001-042) into the AccuBoom node (P/N 063-0172-316). Tighten the bolts on the node connectors to secure the connection. Replace the cover on the machine’s node enclosure.
- Page 14 Chapter 3 Miller Condor G-Series AccuBoom Installation Manual...
-
Page 15: Section Mapping Setup
C h a p t e r 4 Setup This section contains section mapping settings that are used to program the AccuBoom controller. Refer to the controller’s Installation & Operation Manual and the appropriate section in this chapter for programming instructions and section mapping settings for your specific field computer. - Page 16 Chapter 4 Miller Condor G-Series AccuBoom Installation Manual...
-
Page 17: Troubleshooting
AccuBoom system. Note: If the LEDs are not displayed as outlined in the figure below, check the CAN connections and the control cable connections on the node. If the issue persists, contact your local Raven dealer for additional technical support. Note: All boom switches must remain in the On position while AccuBoom control is in operation. - Page 18 Chapter 5 Miller Condor G-Series AccuBoom Installation Manual...
- Page 19 Index AccuBoom Installation Installing the AccuBoom Harness Cable 8 Installing the AccuBoom Node 7 Introduction AccuBoom Kit Contents 5 Point of Reference 4 Preparing for Installation 4 Recommendations 4 Tools Needed 4 Kit Contents Section Mapping Setup Envizio Pro 11...
- Page 20 Index Miller Condor G-Series AccuBoom Installation Manual...
- Page 23 How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
- Page 24 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
