  • Page 1 AGCO Rogator 1254...

  • Page 3: Components Needed

    AccuBoom system. See the Viper Installation and Operators Manual for instructions on setting up the software and using the AccuBoom system. You will also need a valid AccuBoom Control Activation Key for your Viper system in order to activate the AccuBoom system.
  • Page 4 AGCO 1254 Rogator Parallel AccuBoom Installation Manual Notes:...
  • Page 5 H A P T E R N S T A L L A T I O N Use the following procedure to properly install an AccuBoom system on a 1254 Series Rogator sprayer using a Raven console connected to a Raven Viper: 1.
  • Page 6 AGCO 1254 Rogator Parallel AccuBoom Installation Manual 2. Connect the AccuBoom cable to the sprayer boom harness. a. Unplug the Rogator boom cable from the bulkhead connector. b. Tee in the AccuBoom cable (P/N 115-0171-584) between the Rogator boom cable bulkhead connector and the boom harness cable.
  • Page 7 Manual # 016-0171-011 c. Mount the AccuBoom and plate to the mounting standoffs. 5. Connect the AccuBoom cable (P/N 115-0171-584) to the AccuBoom node. a. Connect the rectangular connectors from the AccuBoom cable (P/N 115-0171-584) to the Parallel AccuBoom node...
  • Page 8 8. Connect the 15 pin D-sub connector to the Auxiliary connector on the Viper interface cable (P/N 115-0171-256). 9. The Parallel AccuBoom hardware installation is now complete. Install the Activation Key on Viper and the AccuBoom system is ready for operation.
  • Page 9 RAVEN INDUSTRIES LIMITED WARRANTY WHAT IS COVERED? This warranty covers all defects in workmanship or materials in your Raven Flow Control Product under normal use, maintenance, and service. HOW LONG IS THE COVERAGE PERIOD? This warranty coverage runs for 12 months from the purchase date of your Raven Flow Control Product.
