PICO Controller Menu Structure

Turn on the PICO controller. The display shows:
• After 2 seconds, the type of device
• After 2 more seconds, the NORDSON logo
• The Main Menu
The active menu option or parameter flashes. Parameter changes and manual operation of the PICO controller are
accomplished through the Main Menu using the operating controls (refer to "PICO Controller Operating Controls" on
page 26).
Main Menu
1 Process Data
2 Purge
3 Down-/Upload
4 System Data
www.nordsonefd.com info@nordsonefd.com
Sub-Menu
• Dosing Parameters
• Manual Operation (password code protected*)
• Automatic Mode (displayed in lieu of CAN fieldbus). The inputs for starting the
dispensing processes remain unchanged in the process.
• Level Control (Container, Limit, Remaining)
Valve 1, Valve, 2, Valve 3, Valve 4, All
• Download
• Upload
• Language selection
• Revisions Base (software / hardware release, base card)
• Revisions Ext. (software / hardware release, expansion card)
• Factory Reset (password code protected*)
• CAN (Address, Baud Rate)
• Time / Date
• Display (Brightness, Brightness Save, Contrast)
• Temperature Mode (°C, °F)
• Temperature Output for the valves (0–5 V / 0–10 V, password code protected*)
