PICO Controller Menu Schematic

NOTES:
• The menu structure shows only the operating principle of the individual menu items; not all transitions are visible.
• ESC can be used at any time to return to the previous menu option. However, this is not indicated in the structure
for the sake of clarity.
• Refer to "PICO Controller Menu Structure" on page 25, "PICO Controller Operating Controls" on page 26,
and "Parameters and Value Ranges" on page 27 for information on operation and available settings.
PICO Controller 2+2 V2
Software version 2.1
Automatically continues
after 2 sec
Automatically continues
after 2 sec
Menu
Process Data
Purge
Down-/Upload
System Data
Menu
Menu
www.nordsonefd.com info@nordsonefd.com
Temporary display of the
controller type (after 2 sec)
Temporary display of the
Nordson EFD logo (2 sec)
Process Data
Enter Enter
Dosing Parameters
Manual Operation
ESC ESC
Automatic Mode
Level Control
Menu
Menu
Delay-Time is displayed
only if Cycle = Variable
+1-401-431-7000
Screen saver (displayed after 5 minutes
of no operator action)
Pressing ESC, Enter, or Menu returns
the display to the previous menu
(password may be required)
Current menu
position
Dosing Parameters
Dosing Parameters
Valve 1, Row
Enter
Valve
Pulse Time:
Cycle:
ESC
Cycl. Count:
Turn the Menu dial
to select the valve
Dosing Parameters
Valve 1, Row
ESC
Temperature:
Ext. Puls: 1
Activation: IN1
Dosing Parameters
Valve 1, Row
ESC
Linkage: Z0
Delay: 0.000s
Block Count: 1
Dosing Parameters
Valve 1, Row
ESC
DosingValue: 0.00mg
Stop:
(Delay-Time: 100.00ms)
Sales and service of Nordson EFD dispensing systems are available worldwide.
PICO Controller 2+2-XCH-V2
Display screen
counter
Menu Menu
Menu Menu
Menu Menu
