Installation Example

The following diagram shows a system with two 2-channel PICO Controllers, 4 PICO Toµch controllers, four cables
(P/N 7028222 or P/N 7012975) and four PICO Pµlse valves. The illustrations below provide two examples of how
cable P/Ns 7012975/7028222 can be configured.
PLC
4x P/N 7028222
or 7012975
CAN Multi-
master
Cable P/N 7012975
www.nordsonefd.com info@nordsonefd.com
HMI
+1-401-431-7000
PICO
Controller V2,
2 channel PICO Toµch controllers and Pµlse valves
Sales and service of Nordson EFD dispensing systems are available worldwide.
PICO Controller 2+2-XCH-V2
Cable P/N 7028222
