Signal Level Sources

The following signal levels apply to the input and output signals.
Input level
Affects IN1 to IN10
Affects IN_STOP
Output level
Meaning of OUT_READY 0 V = not ready
Meaning of
OUT_LINE_END
OUT_TEMP_PLC
OUT_FAULT_PLC
Output signal
channels 1–4
The signal levels / potentials of the binary input and output signals can be provided by the internal power supply of
the PICO controller or by a separate source (PLC, power supply unit, or similar device).
The switch stages of the binary input and output signals of the PICO controller are galvanically isolated from the
power supply at the factory. Depending on which source of potential is chosen, the following instructions must be
complied with when connecting to the 25-pin D-subconnector (Channels 1 to 4).
www.nordsonefd.com info@nordsonefd.com
Low 0 to + 5 V
IN1 to IN10 not active
IN_STOP active
= emergency off
0 V
0 V = no response possible
0 V = temperature dispensing
material–fault
0 V = process fault
0 V = no dispensing sequence
+1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.
PICO Controller 2+2-XCH-V2
High +12 to +30 V
IN1 to IN10 is activated
IN_STOP not active
= no emergency off
24 V
24 V = ready
24 V pulse, duration 100 ms
= end of pulse output
24 V = temperature dispensing
material–normal
24 V = process normal
24 V = dispensing sequence active
