Service manual
. ECR tests
The Euro-TX ECR tests allow quick diagnostics of ECR
functions and easier identification of ECR flaws. You can
diagnose the display elements, keyboard keys, printer func-
tions, electronic circuits functions, or other components.
How to run the individual ECR tests:
. Look up "Tests" in the service mode menu or enter code
and press O
E
K
NTER
900.Service mode
960.Tests
. Pick up a group of tests using the arrows or enter its code
and press O
E
(N
K
NTER
960.Tests
962.Display sets
. Select the test you want to run using arrows and press O
E
(N
E
). The ECR will perform the test and prints
NTER
UM
NTER
the test results onto the paper tape.
962.Display tests
2.Complex test
.. Printer tests
Printer tests allow the diagnostics of functions of the printer
or of printer control circuits.
Procedure:
Look up "Printer tests" in the tests submenu using arrows or
enter code and press O
960.Tests
961.Printer tests
... Printing of the character set
Procedure:
Look up "Print char set" in the printer test submenu using
arrows or enter code and press O
961.Printer tests
1.Print char set
(N
E
).
UM
NTER
|
E
).
UM
NTER
|
|
E
E
(N
).
K
NTER
UM
NTER
>
E
(N
E
K
NTER
UM
NTER
>
Testing procedure:
. Display shows "Char set printing" message.
. Depending on the system flag , numeral the printer
prints the ECR information (version number, configura-
tion) and fiscal memory connection onto the receipt and
journal.
. The whole character set is then printed in standard size
along with assigned hexadecimal codes.
Test finishes after the printing of the character set is fin-
ished.
... Printer head position detection test
K
Procedure:
Look up "Prn. head test" in the printer test submenu using
arrows or enter code and press O
961.Printer tests
2.Prn.head test
Testing procedure:
. Display shows the current status for the printer head.
. Status changes with the lifting or lowering the printer
head using the lever.
Test finishes when the E
... Paper tape detection test
).
Procedure:
Look up "Paper sensor" in the printer test submenu using ar-
rows or enter code and press O
961.Printer tests
3.Paper sensor
Successful testing output:
* * * * * * * * * * * * * * * * * * * * * * * * * * * * *
TEST 961.1
E
K
NTER
key is pressed.
SC
Successful testing output:
TEST 961.2
E
(N
K
NTER
Euro
© Elcom s. r. o.
OK
(N
E
).
UM
NTER
|
OK
E
).
UM
NTER
|
fiscal
TX
