Pin 






Tab. .: Thermal head connector pins' description (cntd.)
.. Stepping motors' connectors
Pin 




Tab. .: Description of the stepping motors' connectors (the phase of
the motors are interchanged)
.. Sensors' connectors
Pin 





Tab. .: Description of pins for the sensors' connector (left connector doesn't contain wires
 and )
. Cleaning the thermal head
. Use the blue lever to lift up the thermal head into upper position so it will be separated from the cylinder.
. Dip a cotton swab in alcohol (ethanol) and clean the head using the swab.
. When the alcohol evaporates completely, place the head into printing position using the blue lever.
Warning:
. Never clean the printing head immediately after printing as it may be still hot.
. Do not use sandpaper, scissors, or any other sharp objects to clean the printing head to avoid damage to the printer
head.
. Paper tape cutter
The paper tape cutter is an optional accessory to the printer. This device requires no special maintenance.
Euro  fiscal
TX
Pin desc. Function
STB Activation signal for second half od thermal elements
P-LATCH Latching signal input
PRNCLK Printer clock signal input
DPR Serial data input
VH +V
VH +V
Pin desc.
Phase B (direct signal)
Phase A (direct signal)
Phase B (negated signal)
Phase A (negated signal)
Fig. .: Sensors' connector connexion
Pin desc.
VLED
PS
GND
GND
HS
Function
Step motor control signal
Step motor control signal
Step motor control signal
Step motor control signal
�
�
�
�
�
Function
LED photosensor anode input
Photosensor output
GND
GND
Head position sensor output
Service manual
Fig. .: Stepping motor
connector
� � � � �
Fig. .: Sensors' connector
� � � �

