4.0 MEASURE SAMPLE
4.01 What is MEASURE SAMPLE
4.02 How to Test using MEASURE SAMPLE
4.01 What is MEASURE SAMPLE
MEASURE SAMPLE allows as many readings as required but does not store the data for later use.
NOTE: To store the data, refer to Section 5 PROGRAM MODE.
4.02 How to Test Using MEASURE SAMPLE
Turn the 3M™ Clean-Trace™ NGi Luminometer on. When initialized the screen will display
the MAIN MENU:
The cursor will be pointing at MEASURE SAMPLE. Insert a 3M test device into the
3M™ Clean-Trace™ NGi Luminometer (see section 2.06)
Measuring Samples
To measure a sample, press the SELECT key. The screen will display the word MEASURING
and a series of "count-up" blocks will appear.
The screen will then display the result in Relative Light Units (RLU).
To measure another sample, remove the previous test, insert the next one and press the MEASURE key.
When all measurements are completed press the Back key to return to MAIN MENU.
If the light in the chamber exceeds the range of the instrument, an Overload message will
be displayed.
Press any key to continue.
Overloads occur if the rate of rise of the RLU units exceeds a pre-determined factory set
rate. Accidental overload results may occur, e.g. if the sample chamber is opened while a
measurement takes place. In the case of an overload a repeat measurement can be made
once the cause has been found.
MAIN MENU

Measure Sample

Program Mode
Review Results
Setup Menu
Wed 04 Jan 2012 10:09
Measuring
Please Wait........
52,827 RLU
This result has not been
Stored in the database
Wed 04 Jan 2012 10:09
Back
Overload!
Count exceeded maximum
Wed 04 Jan 2012 10:09
Back
Select
Measure
Measure
