- Page 1 Ground Pro ™ Ground Integrity Meter Model CTM051 User’s Guide...
-
Page 2: Safety Information
Model CTM051 Safety Information Read, understand, and follow all safety information contained in these user instructions prior to use of the 3M Ground Pro Ground Integrity Meter Model CTM051. Retain these user instructions for future reference. EXPLANATION OF SIGNAL WORD CONSEQUENCES Indicates a potentially hazardous situation, which, if not avoided, could result in ... - Page 3 WARNING To reduce the risks associated with environmental contamination: • When working with the automated equipment, always observe safety precautions as recommended by equipment manufacturer and your company’s practices CAUTION To reduce the risks associated with environmental contamination: •...
-
Page 4: Controls And Indicators
The 3M Ground Pro Ground Integrity Meter is a comprehensive instrument that ™ measures the ground connection of your equipment in accordance with ANSI 6.1 and ANSI/ESDA S.20.20 standards. In addition to measuring ground impedance, it also measures AC and DC voltage on the ground as well as the presence of high-frequency noise or electromagnetic interference (EMI) on the ground, alerting you to possible functionality problems, such as tool lockups, erratic behavior and parametric errors. - Page 5 Brief Tour of your 3M Ground Pro ™ Ground Integrity Meter Please refer to the rest of this User’s Guide for detailed explanations of each control, indicator and connection. Banana Jacks Keypad Display Battery Compartment (on the back)
-
Page 6: Installing The Battery
Overview The 3M Ground Pro Ground Integrity Meter measures several important ™ ™ parameters of ground integrity: ground impedance, voltage, and high-frequency noise (EMI) on a ground. Ground connectivity is measured in accordance with ANSI 6.1, ANSI/ESDA S.20.20 and other standards. More specifically, it is measured as AC impedance in a way that is immune to parasitic voltages and currents on a ground. -
Page 7: Low Battery Indicator
If the battery is completely “dead,” there may not even be a beep. Please replace the battery. Press the Power/C button for at least two seconds. The 3M Ground Pro ™... -
Page 8: Impedance Measurements
The impedance mode is indicated by “OH” on the bottom display line. Scaling Impedance Screen The 3M Ground Pro Ground Integrity Meter has ™ four different scales for measuring ground impedance. Choose the appropriate scale for your measurements using the Up and Down arrow buttons. -
Page 9: Voltage Measurements
In this case you will need to repeat this process again. Voltage Measurements The presence of voltage on a ground is never desirable. The 3M Ground Pro Ground Integrity Meter can measure ™ both AC and DC voltages on a ground. - Page 10 Normal measurements indicate that the measured screen impedance is below the specified limit. Unlike a regular multimeter, the 3M ™ Ground Pro Ground Integrity Meter allows you to specify Impedance in Ohms an exact impedance value...
- Page 11 EMI Measurements High frequency noise (EMI) on a ground causes equipment malfunction and damage to sensitive components. The 3M Ground Pro Ground Integrity ™ Meter measures high-frequency noise on a ground in a wide frequency and PEAK dynamic range. Peak EMI in V...
-
Page 12: Hold Function
Hold Function Hold Pressing the Hold button once while in any PEAK Normal measurement mode will cause the 3M ™ measurements Ground Pro Ground Integrity Meter to enter screen the Hold mode. The display will freeze, showing the value at the moment the button was pressed. -
Page 13: Specifications
Please note that if you power down the 3M Ground Pro Ground Integrity ™ Meter while in any of these modes, it will remain in the same mode when the unit is powered up again. Pressing the Hold button one more time puts the Ground Pro back into regular mode. -
Page 14: Regulatory Information
3M. 3M shall not under any circumstances be liable for direct, incidental, special, or consequential damages (including but not limited to loss of profits, revenue, or business) related to or arising out of this certification, including, the use, misuse or inability to use the product. - Page 15 产品中有毒有害物质或元素的名称及含量 Name and Content of Hazardous Substances or Elements 有毒有害物质或元素 (Hazardous Substances or Elements) 部件名称 铅 汞 镉 六价铬 多溴 多溴二 (Part or Component Name) 联苯 苯醚 （Hg） （Cd） （Cr(VI)） (Pb） （PBB） （PBDE） ○ ○ ○ ○ ○ 电容引脚 × (Termination in capacitor) ○...
- Page 16 If this product is defective within the warranty period stated above, your exclusive remedy shall be, at 3M’s option, to replace or repair the 3M product or refund the purchase price of the 3M product. Except where prohibited by law, 3M will not be liable for any indirect, special, incidental or consequential loss or damage arising from this 3M product, regardless of the legal theory asserted.
