5.4.2 Motor rated values
Here we set three very important parameters:
Parameter name
Voltage
Speed
Current
By entering incorrect values in this group you can permanently damage the motor. CS-Lab s.c.
company does not take any responsibility for damage caused by incorrect drive configuration.

5.4.3 Brushless motor parameters (AC/BLDC)

This group applies only to brushless motors. We set the parameters as follows:
Parameter name
R
L
Pole pairs
30
Description
Nominal motor voltage. The value is usually placed on a motor
nameplate.
Nominal motor RPM. The value should be also placed on a motor
nameplate.
Nominal motor current. The value should be also placed on a
motor nameplate.
Description
Motor winding resistance. In current software version this
parameter is not supported and you do not have to enter it. With
future software versions the parameter can be important for
sensorless methods of determining an angle of a rotor a (motor
commutation).
Motor winding resistance. In current software version this
parameter is not supported and you do not have to enter it. With
future software versions the parameter can be important for
sensorless methods of determining an angle of a rotor a (motor
commutation).
Motor pole pairs number. It's very important parameter which
value you can sometimes find on a motor nameplate or in motor
documentation. If we do not have knowledge about number of the
poles pairs then we can verify it by trial and error method. Motors
usually have 4 pairs of poles. It won't damage the motor if you
enter incorrect poles pairs number, it will cause the motor to jerk
and stop. After short time you will see an over current alert or
position and/or velocity tolerance overrun alert.
