3.7 CN5 –CAN and configuration connector (model M4-...040K)
PIN
Signal
number
1
-
2
RxD
3 TxD
4
CAN H
5
GND
6
-
7
-
8
-
9 CAN L
(housing)
Shield
simDrive™ AC Servo Drive - U
Front view of the device's
connector
RS232 – diagnostics and configuration
RS232 – diagnostics and configuration
CAN bus (H signal)
GND (0V)
CAN bus (L signal)
Wire shielding
G
SER UIDE
Description
