5.1.2 csServoManager utility software installation
csServoManager utility is provided as convenient
software
installer
what
installation process runs automatically.
Start the csServoManagerSetup.exe file downloaded
from
www.cs-lab.eu/en
to a package.
Then click „Next >" till the end of the installation
process.
5.2 csServoManager - general rules and notes
In csServoManager utility software there were only necessary options implemented for configuration
and diagnostics. This way the software is simple in operation so you can cope with it easily. Below
you will find rules/notes of using this software.
5.2.1 Connection with a drive
After we start the csServoManager we will see a
window where we choose a drive to connect with
and interface language as well.
First click "Scan" button. You will see all detected
devices in the list. They will be divided into devices
connected through serial port and devices connected
to CSMIO/IP controller via CAN bus.
If the application won't find any devices you should
verify your wiring, logic power supply (24V) and if
USB drive is installed - if we use USB-RS232
converter. You should also verify CAN addresses
assignment (chapter below).
If you will get information about incompatible version you should update your
csServoManager™ and simDrive™ firmware. Always up to date software you will find on
http://www.cs-lab.eu.
You can read more about software update in chapter: „Addition A - Firmware update".
20
basically
makes
or provided on a CD attached
the
simDrive™ - AC Servo Drive User Guide
