Kit parts

The following figure and table show the kit parts.
Table 1: Kit parts list
Figure #
1-1
1-2
1-3
2-1
2-2
2-3
2
2-4
3-1 1
RM3100 Rackmount Kit Instructions
Part number
RM3100
075-1088-xx
016-1964-xx 1
Not saleable
Not saleable
Not saleable
Not saleable
Not saleable
Quantity Description
1 ea RM3100 rackmount kit, includes a front and
back panel set, Instructions, bag of screws and
handles
1 ea Instructions (this document)
—
Standard mounting hardware in plastic bag,
consisting of the following:
2 ea Carrying handles
4 ea (For handles) Screws 8-32 x 1/2 pan head
Phillips
4 ea (For handles) #8 split lock washers
5 ea
Caps
4 ea Screws M 5 x 16 oval head Phillips
4 ea Screws M 6 x 16 oval head Phillips
4 ea Screws 10-32 x 3/4 oval head Poz
4 ea Screws 12-24 x 3/4 oval head Poz
