EVAL-ADIN1300FMCZ
Qty Reference Designator
3 S3, S4, S9
1 T1
1 U1
1 U10
1 U11
1 U12
3 U3, U13, U14
2 U4, U5
1 U7
1 U8
1 U9
1 Y1
1 Y2
1 Y3
Table 8. Not Populated
Qty Reference Designator
26 5V, AVDD3P3_N, AVDD3P3_P,
CLK25, DVDD_N, DVDD_P,
GND1, GND2, GND3, GND4,
GND5, GPCLK, INT_N, LED_0,
LINK_ST, MDC, MDIO, P9, P10,
P11, SUPPLY, VDD0P9_N,
VDD0P9_P, VDDIO_N,
VDDIO_P, XTAL_I
3 C33, C45, C99
1 EXT_12V
1 J1
7 R49, R95, R97, R101, R110,
R111, R120
4 R138 to R141
1 R19
12
R8, R9, R22, R23, R27 to R32,
R37, R38
1 R85
User Guide
Description
16 V, single-pole, 4 throw, rotary
switches, SP4T
Transformer 1000BASE-T magnetic
modules
IC robust, low latency gigabit Ethernet
PHY
IC USB serial UART
IC-TTL single-positive and gate, SC70-5
3.3 V complementary metal-oxide
semiconductor (CMOS) linear regulator
with low quiescent current
IC-TTL dual supply transceivers, 3-state
Dual 300mA adjustable output, low
noise, high power supply rejection ratio
(PSRR) voltage regulators
2
I C compatible serial EEPROM 2-kBit
2
CMOS I C serial EEPROM, 32-kBit.
Ultralow power ARM® Cortex®-M3
Micro-controller with integrated power
management and 256 kB of embedded
flash memory
25 MHz, 10 ppm, crystal, 10 pF load
capacitor
32.768 kHz, 20 ppm, crystal, 6 pF load
capacitor
26 MHz, 30 ppm, crystal, 10 pF load
capacitor
Description
Test point, DNI
Ceramic capacitors, 0.01 μF, 25 V, 10%,
0402, X7R
PCB connector header, 3.81 mm
PCB connector, straight SMA
Resistors, 0 Ω, 50 V, 1%, 0402
Resistors, 0 Ω, R0805
Resistor, 1 MΩ, 1%, 0402
Resistors, 10 kΩ, 1%, 0603
Resistor 10 Ω, 1%, R0402
Rev. 0 | Page 29 of 30
Manufacturer Part Number
NIDEC COPAL CS-4-14NA
Electronics
Pulse Electronics H5007NL
Analog Devices ADIN1300
FTDI CHIP FT232RQ
Texas Instruments SN74LVC1G08DCKR
Analog Devices ADP124ARHZ-3.3-R7
NXP 74AVC1T45GW,125
Semiconductors
Analog Devices ADP223ACPZ-R7
ATMEL AT24C02D-SSHM-T
ONSEMI CAT24C32WI-GT3
Analog Devices ADUCM3029BCPZ
Seiko Epson FA-
128_25.000000MHZ_10.0
_+10-10
Abracon Corp. ABS07-120-32.768KHZ-T
ECS, INC. ECS-260-10-36Q-ES-TR
Supplier Part Number
Keystone Electronics 1405-2
TDK C1005X7R1E103K050EB
Phoenix Contact 1803277
TE Connectivity LTD 5-1814832-1
Multicomp (SPC) MC00625W040210R
Multicomp (SPC) MC 0.1W 0805 0R
Panasonic ERJ-2RKF1004X
Multicomp (SPC) MC0063W0603110K
Multicomp (SPC) MC00625W0402110R
UG-1635
