Source Audio True Spring Reverb User Manual page 34

Neuro App Quick Start (Android)
To establish communication between the Neuro App on an Android device and the pedal, follow
these steps.
1. Make sure the pedal is powered.
2. Connect the included "Neuro cable" (1/4" TRS to 1/8" TRS) between the headphone jack of
the mobile device and Input 2 of the pedal.
3. When the Neuro Mobile App is opened for the first time on an Android device, you will be
prompted to "Calibrate" the device. This function will automatically set the volume level,
Audio Output Channel, and Output Phase on your device so that it properly communicates
with the True Spring Reverb.
4. From the main menu, tap the image of the pedal which you want to control. This action
opens the Effect Editor menu.
5. To test connectivity, move one of the sliders in the Sound Editor. If communication is
working correctly, the small green control LED at the top of the pedal will blink.
6. If the small LED is not blinking when you tap the preset, you have not established
communication between your device and the pedal. In this case hit the "i" icon on the left-
hand corner of the Main Menu. This will open the About page. Scroll to the bottom of the
page and select the Volume Calibration button to reestablish communication.
7. If you're still have problems connecting the Neuro Mobile App to the True Spring Reverb,
email us at contact@sourceaudio.net.
SA247 True Spring Reverb User Guide 34
