Source Audio True Spring Reverb User Manual page 15

Creating a Preset (Without the Neuro Desktop Editor)
•
Bypass the True Spring Reverb by clicking the footswitch once. The engage/bypass LED should
be dark at this time.
•
Press and hold the footswitch for 5 seconds and wait for the engage/bypass LED to turn red.
You are now in Preset Mode.
•
Set up the effect how you want it to sound, including the effect switch, MIX, LEVEL, DWELL, and
TONE knobs. You can also adjust the Tremolo type and the DEPTH and RATE parameters. Once
you have made a change, the engage/bypass LED will begin to blink.
•
To save your preset, hold down the footswitch until the LED blinks rapidly 3 times.
•
Now, each time the effect is engaged and in that Effect Switch position, the saved preset will be
recalled.
•
You may save one preset in each of the three switch positions for a total of three.
•
One preset can be saved in each of the three Effect Switch positions.
•
Additional parameters can be accessed when creating True Spring presets, using the Neuro
Desktop Editor and Neuro Mobile App. Go to the
creating and saving presets.
Editing a Preset
•
Activate preset mode. The engage/bypass LED will be solid red.
•
Select a preset with the Effect Toggle Switch and change any parameter you wish. Once you
have made a change, the engage/bypass LED will begin to blink.
•
When you are ready to save, press and hold the footswitch for a few seconds. The LED will blink
three times to show that the preset was saved.
Quick Preset Switching
Using the Neuro Mobile App or Desktop Editor, it is possible to configure an option that speeds up
the process of switching between Standard and Preset Mode. To make this change go to the Neuro
Hardware Options page and select "On" from the "Quick Change to Preset Mode" dropdown menu.
In this mode, Preset Mode activates in 800 ms instead of 5 seconds.
SA247
Neuro Desktop Editor
True Spring Reverb User Guide
section for info a
15
