Source Audio True Spring Reverb User Manual page 23

Selecting the Control Input Option
Visit the Hardware Option
function of the Control Input.
To select the function of the Control Input without the Neuro Editor, follow the process below:
1. Hold down the CONTROL INPUT button while powering up the pedal.
2. The Control Input LED on the top of the pedal will begin a sequential blinking pattern of one
blink, two blinks, and three blinks.
3. Release the CONTROL INPUT button after the corresponding blink number to assign the
function of the Control Input. The corresponding blink numbers are as follows:
o One Blink: Neuro Hub/Expression Pedal
o Two Blinks: Tap Tempo
o Three Blinks: Tremolo Bypass/Engage
The Source Audio Tap Switch is included in the True Spring Reverb/Tap Switch Bundle, but can also
be purchased separately at
SA247
section of the Neuro Desktop Editor for instructions on assigning the
Source Audio's Reverb.com
True Spring Reverb User Guide
Webstore.
23
