"micro" label facing upward. Refer to Fig. 3-1b and 3-1c.
Note: You can hear a clicking sound if you insert the TF card in the right
place. Press the card slightly, it will be ejected automatically.

3.1.3 Connections

Cable ( wired connection) Connection Procedure of X-431 Diagun III:
Insert the TF card into the slot;
Connect one end of the X-431 Diagun III main unit diagnostic cable to
the USB port of X-431 Diagun III main unit;
Link the other end of X-431 Diagun III main unit diagnostic cable with
the Micro USB port of the DBScar diagnostic connector;
Find out the vehicle's DLC;
Connect the other end of DBScar diagnostic connector to the vehicle's
DLC and the power indicators of X-431 Diagun III and DBScar
connector will light up.
Bluetooth (wireless) Connection Procedure of X-431 Diagun III:
Insert the TF card into the slot;
Find out the vehicle's DLC;
Plug the 16 PIN end of DBScar diagnostic connector into the vehicle's
DLC.
