LAUNCH
Fig. 3-15
Fig. 3-16
X-431 Diagun III English User's Manual
Click [OK], the dynamic data of the
selected datastream item would be
displayed, as shown on Fig. 3-15.
Click [Record]
datastream in a specific duration, click
[Stop] to complete the record.
Button Descriptions:
[Graph]: display the waveform of a
single datastream item.
[Record]:
datastream in a specific duration
(the button will shift to [Stop] after
being clicked).
In Fig. 3-15, select the desired
datastream, and click [Graph] to view
the datastream waveform (not more
than two in a screen) as shown on the
left.
25
to save dynamic
record dynamic
