LAUNCH
Fig. 3-5
Fig. 3-6
X-431 Diagun III English User's Manual
On vehicle selection interface, click
DEMO and the screen will enter version
selection interface (See Fig. 3-5), select
the version you need.
Note: The operations of other makes and
models, and systems are the same as
DEMO. See relevant system operation
introduction for details, and here we only
take demo program for example.
Button description:
[OK]: proceed to the next step.
[Return]: return to the previous
screen.
[Help]: view help information.
[About]: view copyright statement.

3.3 How to Diagnose

Select version "V41.60" in Fig 3-5, and
click [OK] to enter the diagnosis screen,
as shown on Fig. 3-6.
Note: The diagnosis screen of different
makes contains the tested models,
systems, diagnosis connector and DLC
location. The operations are similar.
20
