4" Standard Pump Installation, Operation & Service Manual
16. Install excess wire into wiring compartment. Replace wiring compartment cover. Torque to 35 ft-lb (50 N•m).
Thread sealant should not be used.
17. Apply an adequate amount of fresh, UL classified for petroleum, non-setting thread sealant to the threads of
the riser pipe. Install eyebolt plug, using an adequate amount of fresh, UL classified for petroleum, non-setting
thread sealant, and torque to 50 ft-lb (70 N•m).
WARNING! For fixed length pumps:
Confirm that the lifting eyebolt is properly torqued to 10 ft-lbs (13.6 N•m) with a minimum of 6 full threads
installed. Occasionally, eyebolts are removed after pump installation and corrosion may occur in the
threaded areas of the wiring compartment cover (eyebolt plug) and the eyebolt. If corrosion has occurred,
the cover and eyebolt should be replaced.
Utilize the lifting eyebolt to suspend the pump vertically and then install the pump onto the riser pipe until
watertight and in alignment with the piping to the dispensers.

Conduit Box Wiring

OFF
DANGER! Always disconnect, lock out, and tag the power before starting to service the pump.
1. Connect electrical conduit approved fittings to conduit box.
2. Remove cover from conduit box
3. Connect wires from power supply to wires in the conduit box. Install ground wire from power panel (see
Figure 14) as shown. Thread sealant required on single box.
4. For Dual Box: Inspect o-rings on access covers, replace if necessary. Lubricate o-rings with petroleum based
jelly. Reinstall access covers. Torque 35-ft-lbs (50 N•m). Do not use thread sealant on dual box.
5. For Single Box: Apply an adequate amount of fresh, UL classified for petroleum, non-setting thread sealant to
the 2" NPT plug and torque until watertight.

For three Phase Pumps (Without Capacitor)

See Figure 17 for Steps 1 through 4.
1. Conect the orange wire from the manifold's female connector to M1 from the output of the control box.
2. Connect the black wire from the manifold's female connector to M2 from the output of the control box.
3. Connect the red wire from the manifold's female connector to M3 from the output of the control box.
4. Connect the ground wire from the power panel to the ground screw in the conduit box.
5. For Dual Box: Inspect o-rings on access covers, replace if necessary. Lubricate o-rings with petroleum based
jelly. Reinstall access covers. Torque 35-ft-lbs (50 N•m). Do not use thread sealant on dual box.
6. For Single Box: Apply an adequate amount of fresh, UL classified for petroleum, non-setting thread sealant to
the 2" NPT plug and torque until watertight.
18
