Red Jacket Quick-Set AGUMP33R1 Installation, Operation & Service Manual page 14

4" Standard Pump Installation, Operation & Service Manual
X4P150S17T1, X4AGP150S17T1
X4P150S17T2, X4AGP150S17T2
X4P150S17T3, X4AGP150S17T3
X4P150S17T4, X4AGP150S17T4
Table 3 shows pump electrical service requirements for UMPs with end view A and Table 4 shows pump elec-
trical service requirements for UMPs with end view B.
Table 3.- Electrical Service Information (Use for UMPs Containing a Franklin Motor with End View A)
Required power supply rating for 60 Hz, 1 phase motors is 208 - 230 Vac. For 50 Hz, 1 phase motors, required rating is 220 - 240 Vac.
3 phase motors required rating is 380 - 415 Vac.
UMP Model No. HP
AGUMP33R1, 1/3
UMP33R1
AGUMP75S1, 3/4
UMP75S1
AGUMP150S1, 1-1/2
UMP150S1
X3AGUMP150S1, 1/1/2
X3UMP150S1
AGUMP75S3-3, 3/4
UMP75S3-3
AGUMP150S3-3, 1-1/2
UMP150S3-3
X4AGUMP150S3, 1-1/2
X4UMP150S3
AGUMP75S17-3, 3/4
UMP75S17-3
AGUMP150S17-3, 1-1/2
UMP150S17-3
X4AGUMP150S17, 1-1/2
X4UMP150S17
Table 2.- Distance From Eye Bolt to Inlet
MODEL#
Voltage
Fluctuation
Range
Hz PH Min. Max. Amps
60 1 200 250
60 1 200 250
60 1 200 250
60 1 200 250
50 1 200 250
50 1 200 250
50 1 200 250
50 3 342 457
50 3 342 457
50 3 342 457
COMPRESSED
in mm
74.5 1892
97.5 2476
131.5 3340
131.5 3340
Winding Resistance (Ohms)
Max. Locked
Load Rotor Black-
Amps Orange
4 13 7.7 - 9.4
6.5 25 2.9 - 3.6
10.5 37 2 - 2.5
10.5 37 2 - 2.5
5.8 17 3.6 - 4.5
10 28 2.5 - 3.1
10 28 2.5 - 3.1
2.2 11 25.8 - 32.4
3.8 15.8 13.1 - 16.4
3.8 15.8 13.1 - 16.4
9
EXTENDED
in mm
101.5 2578
131.5 3340
198.5 5041
165.5 4203
Capacitor Kit
Red- (µF) or Heaters
Orange Black-Red
17.4 - 21.2 25 - 30.7 144-224-5 (17.5)
14.9 - 18.2 17.7 - 21.9 144-224-5 (17.5)
11.6 - 14.2 13.5 - 16.8 144-225-5 (25)
11.6 - 14.2 13.5 - 16.8 144-225-5 (25)
20.4 - 25 23.9 - 29.6 144-224-5 (17.5)
11.5 - 14 13.9 - 17.2 144-225-5 (25)
11.5 - 14 13.9 - 17.2 144-225-5 (25)
25.8 - 32.4 25.8 - 32.4
13.1 - 16.4 13.1 - 16.4
13.1 - 16.4 13.1 - 16.4
Specifications
(KXX)
K26
K33
K33
