Red Jacket Quick-Set AGUMP33R1 Installation, Operation & Service Manual page 10

4" Standard Pump Installation, Operation & Service Manual
20" (508 mm)
DRIVEWAY
GRADE
11'' (279 mm)
ELECTRICAL
CONDUIT BOX
(254 mm)
6" (152 mm)
PUMP
(508 mm)
(305 mm)
4'' RISER
10''
13''
(330 mm)
TANK
Figure 1. Leak detector and manifold dimensions
Leak Detector Installation and Manifold Dimensions
RED JACKET LEAK
DETECTOR
8-3/4" (222 mm)
20"
12"
RED JACKET
LEAK DETECTOR
RED JACKET
SUBMERSIBLE
PUMP
5.5'' (140 mm)
TANK
20'' X 20'' (508 mm X 508 mm) MANHOLE
RED JACKET
LEAK DETECTOR
2-INCH OUTLET
TO DISPENSERS
5
FLEX
CONNECTOR
RED JACKET
SUBMERSIBLE
PUMP
153-1.eps
