CraftBot CB4 FLOW Series User Manual page 16

• If the deviation is large, the dashes are dense and several
arrows indicate which direction the knob under the
current position is rotated will result in a better reading.
• For smaller deviations, the stripe is more scattered and
only one arrow indicates the rotateing direction.
• To achieve optimum value, the meter should be wrapped
between two prominent lines.
• After 3 optimal measurements, the NEXT button
appears. If one or more of the 3 measurements is out of range, the
calibration will not continue and will need to be adjusted on the button.
• After pressing the NEXT button, the head is positioned above the back
right button and then above the back left button screw.
• Repeat the procedure for the other buttons.
• Mesh bed
• Both calibrations are performed by the printer without external intervention
or adjustment.
•
There are a few important rules to follow before calibrating!

Heat up the nozzle and remove the filament from the extruder.

Clean the plate and the nozzle tip.

Make sure the metal plate is pushed back as far as it will go.
