Installation Guide
Figure 4: Component Layout
1.3 Ultrastar Data60 Specification Summary
Table 2: Environmental Specification Summary
Specification
Temperature Gradient
Temperature De-rating
Relative Humidity
Relative Humidity Gradient
Table 3: Electrical Specifications
Specification
Max Power Consumption
Typical Power Consumption
PSU Connector Type
* Max and typical power consumption values represent the output power to the system. Input power will vary depending
on the PSU efficiency and load sharing between PSUs.
Non-Operational
Temperature
1°C per 300m above 3000m
8-90% Non-Condensing
30% per hour maximum
Altitude -300m to 12,000m /
-984 ft. to 39,370 ft
*
Input Voltage
PSU Efficiency

1.3 Ultrastar Data60 Specification Summary

-40°C to 70°C
30°C / Hr
~1250W
~1000W
200 - 240 VAC
80 PLUS Platinum
Operational
5°C to 35°C
20°C per hour maximum
1°C per 300m above 900m
8-90% Non-Condensing
30% per hour maximum
-300m to 3048m /
-984 ft. to 10,000 ft.
Value
C14
1. Overview
