BCM91125PCIX
S
WITCHES
Figure 8 shows the positions of switches numerically. Compare
of each switch in
Board ID Function
SW3 Cold Reset asserted when the button is pressed
SW5 Power toggled on or off when pressed
SW10 8-position DIP switch, for board configuration dip[8:1]
dip[8] = reserved
dip[7] = System byte order (on = big endian; off = little
endian)
Page 16

Switches

Table 6.

Figure 8: Switch Callouts

Table 6: Switch Descriptions

B roadc om C or por ati on
Figure 8's number callouts with a description
Default
N/A
N/A
off
on
Document 91125PCIX-UM100-R
User Manual
07/02/04
