BCM91125PCIX
Board ID
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D20
D21
D22
D23
D31
D32
U74
Page 12 LEDs
Color Description
Green PHY 0 Slave indicator
Green PHY 0 Receive indicator
Green PHY 0 Transmit indicator
Green PHY 0 Full-duplex indicator
Green PHY 0 Link 1 indicator
Green PHY 0 Link 2 indicator
Green PHY 1 Slave indicator
Green PHY 1 Receive indicator
Green PHY 1 Transmit indicator
Green PHY 1 Full-duplex indicator
Green PHY 1 Link 1 indicator
Green PHY 1 Link 2 indicator
Green 1.2V BCM1125 Core Power good indicator
Green 5V Power good indicator
Green 3.3V Power good indicator
Green 2.5V Power good indicator
Red RESET_OUT active indicator
Red COLD_RESET active indicator
Green Four-character LED display
B roadc om C or por ati on

Table 3: LED Descriptions
