Section 5: Troubleshooting; Corrective Procedures; Replacement Parts; Table 15: Replacement Parts - Broadcom BCM91125PCIX User Manual

BCM91125PCIX
C P
ORRECTIVE ROCEDURES
1 When CFE is not able to initialize the system and reach the console prompt, the four-character alphanumeric
LED display may be used to help debug the initialization sequence. When the Cer2 message appears, a cache
error has occurred. This frequently occurs when the BCM1125H is either undercooled or is in a low-voltage
situation. Ensure that the correct voltage and cooling is being provided. For other LED message descriptions,
refer to the Common Firmware Environment (CFE) Specification document.
2 There is no output coming from the serial boot console, but the four-character LED displays CFE . Because
CFE uses serial port 0 by default, ensure that a standard 9-pin RS232 null-modem cable connection is being
used. Also ensure that the terminal program is set to a baud rate of 115200, 8-bit, no parity, no flow control.
R
EPLACEMENT
Board
Description
ID
F5, USB 5V, 1A current
F6 limit fuse
F7 EJTAG 3.3V, 1A
current limit fuse
BT1 3V Li RTC battery
Page 22 Troubleshooting
Section 5: Troubl eshooting
P
ARTS

Table 15: Replacement Parts

Manufacturer
Littelfuse
various
B roadc om C or por ati on
Manufacturer ID Web Information
® 154001
CR2032
User Manual
http://www.littelfuse.com/data/
Data_Sheets/154.pdf
Document 91125PCIX-UM100-R
07/02/04
