Section 2: Getting Started - Broadcom BCM91125PCIX User Manual

BCM91125PCIX
Complete the following steps to get to a BCM91125PCIX CFE (firmware) prompt.
1 Connect a 9-pin null modem cable to the serial port of the BCM91125PCIX and a serial port on a workstation/
PC.
2 Use a terminal program and set it to 115200 bps, 8-bit data, 1-stop bit, no parity, and no flow control.
3 Power up the BCM91125PCIX by plugging in the provided cable to the power supply socket on the back of the
box and into a wall socket. Then hit the power button on the front panel.
After a short delay, the CFE initialization output and serial console prompt should display. The following is an
example of the output:
CFE version 1.0.41 for BCM91125PCIX (64bit,SP,BE,MIPS)
Build Date: Mon May
Copyright (C) 2000,2001,2002,2003 Broadcom Corporation.
Initializing Arena.
Initializing PCI. [normal]
PCI bus 0 slot 0/0: SiByte, Inc. BCM1250 PCI Host Bridge
PCI bus 1 slot 1/0: Advanced Micro Devices (PLX) HT7520 PCI-X Tunnel
PCI bus 1 slot 1/1: Advanced Micro Devices (PLX) HT7520 PCI-X IOAPIC
PCI bus 1 slot 2/0: Advanced Micro Devices (PLX) HT7520 PCI-X Tunnel
PCI bus 1 slot 2/1: Advanced Micro Devices (PLX) HT7520 PCI-X IOAPIC
Initializing Devices.
BCM91125PCIX board revision 1
PCIIDE: 0 controllers found
Config switch: 2
CPU: 1125H A2
L2 Cache: 256KB
SysCfg: 0080000020DB0860 [PLL_DIV: 16, IOB0_DIV: CPUCLK/3, IOB1_DIV: CPUCLK/2]
CPU type 0x40103: 800MHz
Total memory: 0x20000000 bytes (512MB)
Total memory used by CFE:
Initialized Data:
BSS Area:
Local Heap:
Stack Area:
Text (code) segment:
Boot area (physical):
Relocation Factor:
CFE>
4 At the prompt, a program can be run via the network from a TFTP server by doing the following:
a. Connect the BCM91125PCIX Ethernet port E0 with an Ethernet cable to a switch, repeater, or directly to
the Ethernet port of the file server.
b. To initialize Ethernet port E0, type the following:
Page 4 Getting Started
S e c ti o n 2 : G e t t i ng S t a r t e d
3 20:13:58 PDT 2004 (mpl@lc-sj1-091)
Note: Because the Broadcom PHYs handle direct connects automatically, a crossover cable for
direct connects is not needed.
B roadc om C or por ati on
0x8FE84280 - 0x90000000 (1555840)
0x8FE84280 - 0x8FE8DE70 (39920)
0x8FE8DE70 - 0x8FE8E5E0 (1904)
0x8FE8E5E0 - 0x8FF8E5E0 (1048576)
0x8FF8E5E0 - 0x8FF905E0 (8192)
0x8FF905E0 - 0x8FFFFFB0 (457168)
0x0FE43000 - 0x0FE83000
I:F03905E0 - D:0DF84280
