PMOD Connector (J6)

This is a 2×6, right angle, female connector. It is used to provide a Digilent PMOD-compatible I
2
the I C pins duplicated on the upper and lower connector rows.
Figure 10 shows the J6 PMOD connector detail.
Table 8 shows the J6 PMOD connector pinout.
Pin
1
2
3
4
5
6
a. The Wi-Fi module net name for this signal is MICRO_I2C2_SCL.
b. The Wi-Fi module net name for this signal is MICRO_I2C2_SDA.

Power

+5V is sourced from the Micro-USB connector (J5). 3.3V regulation is done by an onboard 1.5A linear regulator.

Pushbutton Switches (SW1 and SW2)

The carrier board has two vertically activated pushbutton switches. SW1 is the board reset and SW2 is for users
to define via application software.
Switch
SW1 (RESET)
SW2 (USER)
Broadcom
®
November 19, 2015 • WICED-UM200-R

Figure 10: J6 PMOD Connector Detail

Table 8: J6 PMOD Connector Pinout

Wi-Fi Module Net Name
–
–
a
SCL
b
SDA
GND
VCC

Table 9: Pushbutton Switches Pinouts

Pin
36
34
Pin
7
8
9
10
11
12
Wi-Fi Module Pinout
Net Name
MICRO_RST_N
MICRO_GPIO_A
Interfaces
2
C interface with
Wi-Fi Module Net Name
–
–
a
SCL
b
SDA
GND
VCC
