Section 1: Product Overview; Introduction; Items Included With The Shipment; Features - Broadcom BCM91125PCIX User Manual

User Manual
07/02/04
I
NTRODUCTION
The BCM91125PCIX evaluation board is an evaluation platform intended to support the needs of prospective
users of the BCM1125H processor. This user manual provides information on how to get the BCM91125PCIX
evaluation board up and running quickly. This manual also describes how to locate, configure, and observe
the various connectors, switches, jumpers, and LEDs on the BCM91125PCIX, allowing software development
and evaluation of the BCM1125H processor to begin.
For additional information on this board and the BCM1125H processor, go to:
http://sibyte.broadcom.com/public.
I I
TEMS NCLUDED WITH THE
The following items are included with the BCM91125PCIX evaluation board shipment:
• BCM91125PCIX evaluation board in ATX case with power supply and power cable
• OCDemon Macraigor Systems Wiggler parallel port JTAG probe
• Viosoft ARRIBA
• This document
F
EATURES
This section describes the BCM91125PCIX's features.
H
ARDWARE
• BCM1125H processor
• microATX form factor board mounted in ATX case with a power supply (AC Input: 115V/230V, 10A/5A, 60
Hz/50 Hz; DC Output: 230W)
• Two DDR SDRAM DIMM slots
- Ships with two 256MB PC2100 (266 MHz) w/ ECC DIMM
• Two 10/100/1000 Mbps Ethernet interfaces with RJ45 connectors
• Two UARTs with RS232 interface
• One 32-bit, 33/66-MHz, 3.3V PCI connector
• Two 64-bit, 33/66-MHz, 3.3V PCI-X connectors
• 2 MB Flash ROM
• Two SMBus channels with the following devices connected:
- RTC
- EEPROM
- Temperature sensor
- DIMMs SPD EEPROMs
• Two USB connectors
Document 91125PCIX-UM100-R
Section 1: Product Over v iew
S
HIPMENT
®
Embedded Edition CD
B roadc om C or por ati on
BCM91125PCIX
Product Overview Page 1
