Raven PowerGlide AutoBoom Operator's Manual page 5

Calibrating a
System
Use this procedure if this is the first time you are calibrating the system.
Important:
• the hydraulic installation has been completed
• the wheels are attached to the boom and are on the ground
• the system hydraulics are warmed to normal operating
temperatures
• the engine RPMs are adjusted to a level that allows full
hydraulic capacity
• Pull type sprayers need to have the tractor hydraulics
running in a continuous flow mode.
1. Unfold the booms and lower them until the boom mounted wheels are
resting on the ground.
Manual # 016-0130-061 Rev A 10/06
C
Before beginning calibration, ensure that:
C
H A P T E R
A L I B R A T I O N
3
