FarmTek 108681 Quick Start Manual page 4

LAWN AND GARDEN
ASSEMBLY INSTRUCTIONS
1. Turn the frame upside down and attach the tool tray
using the two (2) flat plates and 6x12mm pan head
bolts, washers, and nuts. Do not tighten the bolts at
this time.
NOTE: Set the seat aside on a surface that will not
scratch or damage the finish. It is installed last.
2. Center the tool tray on the frame and tighten all
6x12mm bolts.
4
108681
Rolling Work Seat
3. Slide the axles into the frame.
4. Slide one (1) wheel washer, one (1) wheel, and one (1)
additional wheel washer onto each end of the axles.
Mount wheels with the valve stem to the outside of the
work seat.
Revision date: 05.01.12
