(1) Voltage
(A) Brown
(B) Blue
(C) Green/yellow
(2) Wastewater pump
(D) Green/yellow
(E) Blue
(F) Brown
Connection diagram (Duo Tronic)
L N PE PE
A B C D
1
016-102_01 DE_EN_FR
(3) Float switch
(K) Yellow
(L) White
(M)
(N) Brown
(O)
(P) Green
(Q) Not used
N L PE N L
E F G H J
2 3
Pumping station / Installation and operating manual
(4) Alarm
(T)
(U)
Pink
Grey
I1 - I2 -
K L M N
4
Connection for external remote sig-
nal generator / potential-free contact
Connection for external remote sig-
nal generator / potential-free contact
I3 - I4 - #
O P Q R S
- +
T U
5
