Instruction Manual
1

History

Ver. Date
1.0 2013-01-28
1.1 2015-07-07
2

General Information

The NS-xx/DPG2-RUx is a µC controlled inclinometer for industrial applications. The NS-xx/DPG2
features a measuring range up to ± 30°.

2.1 Features

•
two inclination sensor cells based on a conductance measurement principle
•
electronic excitation and readout of the cell signal
•
digital linearization
•
temperature compensation
•
outputs RS232 & voltage

2.2 Type and order codes

Required type of product can be ordered by use of one of the following part numbers:
Type
NS-5/DPG2-RUD
NS-10/DPG2-RUG
NS-15/DPG2-RUG
NS-30/DPG2-RUN
3 General Information
Thank you for purchase of a DPG2-Series inclinometer from Measurement Specialties.
This manual offers information on the proper installation and operation. For further technical
information on the performance of the DPG2-Series inclinometer, please see the Specification,
DPG2-Series inclinometer
MEAS Deutschland GmbH
Hauert 13, D-44227 Dortmund, Germany
DPG-Series Inclinometer
Purpose
Creation
Update Chapter 3.1 Point 7 & add. Minor changes
Update of Fig. 5.2, Dimensions & Weight
Measurement angle
+/- 5° RS232, voltage
+/-10° RS232, voltage
+/-15° RS232,voltage
+/-30° RS232 ,voltage
www.meas-spec.com
3 of 15
July 2015
Output Supply
+7... 30 VDC
+7... 30 VDC
+7... 30 VDC
+7 ... 30VDC
Author
M.Zürn
F.Schwieger
Order number
G-NSDPG2-003
G-NSDPG2-001
G-NSDPG2-002
G-NSDPG2-005
