Instruction Manual
6

Interface

6.1 Digital Output RS232

For digital communication, the standardized RS 232-Interface (V24) is used in duplex mode.
After startup the sensor transmits the angle values in degrees (°) continuously.
6.1.1

Electrical Levels

RS232:
PARAMETER
V High-level output voltage
OH
V Low-level output voltage
OL
I High-level input current
IH
I Low-level input current
IL
(‡)
I Short-circuit output current
OS
Ω
Output resistance
O
(†) TA = 25°C.
(‡) Short-circuit durations should be controlled to prevent exceeding the device absolute power-dissipation ratings, and no more
than one output
6.1.2 Interface parameter for all NS–xx/DPG2–RUx (except NS–30/DPG2-RUN)
Baud rate: 9600 Baud
Format: ASCII, 8 data bits, 1 stop bit, no parity
String length: 22 byte
Layout: < D0 ... D21>
D0 ... D10
D11 ... D21
6.1.3 Interface parameter for NS–30/DPG2–RUN
Baud rate: 9600 Baud
Format: ASCII, 8 data bits, 1 stop bit, no parity
String length: 20 byte
Layout: < D0 ... D19>
D0 ... D9
D10 ... D19
MEAS Deutschland GmbH
Hauert 13, D-44227 Dortmund, Germany
DPG-Series Inclinometer
TEST CONDITIONS
D at R = 3 kΩ to GND, D
OUT L
GND
D at R = 3 kΩ to GND, D
OUT L
V = VCC
I
V at 0 V
I
Vcc = 5.5 V, V = 0 V
O
Vcc, V+, and V− = 0 V, V
= "X=±xx.xxx", <CR>, <LF>
with D2 = sign (+ or -)
with D5 = point
= "Y=±xx.xxx", <CR>, <LF>
with D13 = sign (+ or -)
with D16 = point
= "X=±xx.xx", <CR>, <LF>
with D2 = sign (+ or -)
with D5 = point
= "Y=±xx.xx", <CR>, <LF>
with D12 = sign (+ or -)
with D15 = point
www.meas-spec.com
10 of 15
July 2015
MAX TYP
(†)
=
IN
−5 −9
= VCC
IN
200 15
−1
±10
60
= ±2 V
300
O
Example:
...
X=+00.430
Y=-00.084
...
Example:
...
X=+00.43
Y=-00.08
...
MIN UNIT
9 5 V
V
µA
−20
µA
5 0
−60
mA
Ω
