Solid State Logic C200 Installation Manual page 65

Mic Input Card ('908)
+5V
SPLIT OUTPUTS
7-12
1-6
MIC IN
1 - 12
MIC In 1 – 12
Location:
Connector Type:
Cct Hot
1 D
2 C
3 A
4 B
5 V
6 U
7 R
8 S
9 n
10 m
11 k
12 l
Split Outputs 1 – 6
Location:
Connector Type:
Cct Hot
1 24
2 10
3 21
4 7
5 18
6 4
Split Outputs 7 – 12
Location:
Connector Type:
Cct Hot
7 24
8 10
9 21
10 7
11 18
12 4
908 Micamp
Varicon 56-way female
Cold Screen
K P All other pins unused
J N
E L
F M
Z d
Y c
W a
X b
t y
s x
p u
r v
908 Micamp
25-way D-type female
Cold Screen
12 25 Pin 13 unused
23 11
9 22
20 8
6 19
17 5
908 Micamp
25-way D-type female
Cold Screen
12 25 Pin 13 unused
23 11
9 22
20 8
6 19
17 5
Appendix C – Connector Pinouts
Notes
Notes
Notes
Page 61
