Solid State Logic C200 Installation Manual page 54

C200 Installation Guide
Centuri Processor Crate
Parameter Condition
Height
Width
Case only without rack ears
Depth
Weight (†)
Heat Dissipation 32 DSP, no I/O
64 DSP, 24 mics, 48 analogue
128 DSP, 48 mics, 96 analogue
Voltage Range
Current Maximum over voltage range
Power Factor
Fusing Thermal current trip. No fuses
Noise
Connectors Power in 1 and 2
Network
Sync in
Video out 1, 2 and 3
Serial
Control Surface
Machine Control
Timecode
Control Power Indicators
Remote Power Indicators
Expansion
MIDI
† Centuri must be supported on rack shelves. Do not rely on the rack ears alone.
Page 50
Value Unit
15 U
665 mm
19 in
449 mm
592 mm
35 – 45 kg
300 W
550 W
910 W
100 – 240 V
12.3 – 4.9 A
0.95
16 A
75 dB(A)
IEC male
RJ45 100 baseT
BNC 75Ω analogue video
HD15 female
62-way HD D-type female
3M™ MDR high-density 50-way female
25-way D-type male
25-way D-type female
25-way D-type female
9-way D-type male
25-way D-type female
5-pin 180° DIN female
Notes
excludes connectors/cables
depending on I/O fitted
minimum
typical
maximum
AC only
approximately
each input
approximately
9-way breakout lead supplied
unused
unused
