Appendix C: Connector Pinouts – C200 Console
Meter Inputs
Location:
Connector Type:
pin Description
1 Meter 1 input
14 Meter 1 input
2 n/c
15 Meter 2 input
3 Meter 2 input
16 n/c
4 Meter 3 input
17 Meter 3 input
5 n/c
18 Meter 4 input
6 Meter 4 input
19 n/c
7 Meter 5 input
20 Meter 5 input
8 n/c
21 Meter 6 input
9 Meter 6 input
22 n/c
10 Meter 7 input
23 Meter 7 input
11 n/c
24 Meter 8 input
12 Meter 8 input
25 n/c
13 n/c
Note. If both the RTW phasescope and mechanical meters are fitted refer to the RTW circuit allocations.
(Analogue Circuits)
Audio Belly Panel
25-way D-type male
Notes: VU or PPM only
+ Left meter
-
+ unused
-
+ Right meter
-
+ unused
-
+ unused
-
+ unused
-
+ unused
-
+ unused
-
Appendix C – Connector Pinouts
Notes: RTW10830
Input 1
and Left meter
Input 2
and Right meter
Input 3
Input 4
Input 5
Input 6
Input 7
Input 8
