Installation Wiring
Section 5
DAW Midi Connection (Option)
If the DAW option is specified, then a separate 1U breakout panel is provided for access to the system's Midi circuits .This
should be connected to the lower rear panel of the Centuri chassis and mounted in a suitable position in the equipment
rack.
Connector pairs 1–4 are available for integration with a DAW system. Each connector can control 8 audio channels. An
independent feed of Midi timecode is provided on a separate connector. Note that Midi connectors 5–12 are not
implemented at this time and are reserved for future expansion.
Standard Midi 5-pin DIN cables should be used to connect the workstation.
Note:The 'Expansion' connector has no function on C200.
Page 47
