C200 Installation Guide
Section 1 – Introduction
The object of this manual is to provide purchasers of the C200™ Console and Centuri™ Processor with information in
the following areas:
• Safety considerations
• Installation requirements
• Items supplied:
• Installation:
• Specifications and Physical dimensions
• Pinouts of standard connectors
The information provided by this manual is relevant to all of the versions of the C200.
The aspects of the C200 which can be customised – frame size, channel layout, meter panel as examples – will be fully
documented in the Custom Specification information for a specific console.
The Custom Specification information, which details the actual console as built, will be found in Section 10 of the console's
Service Manual.
Page 2
– Main components and optional items
– Physical assembly
– Electrical connections and cabling
– System options
