Dsub-25 - Aes3 - DirectOut Technologies EXBOX.AES User Manual

PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
page 54 of 60

DSUB-25 - AES3

The pinout of the DSUB-25 connectors for the
transmission of AES3 audio signals follows the
AES59 specifi cation.
13 12 11 10 9
25 24 23 22 21 20 19 18 17 16 15 14
jack - female
Signal digital
CH 4 OUT +
GND
CH 3 OUT −
CH 2 OUT +
GND
CH 1 OUT −
CH 4 IN +
GND
CH 3 IN −
CH 2 IN +
GND
CH 1 IN −
Appendix A - Wiring Sketches
8 7 6 5 4
PIN
14
15
16
17
18
19
20
21
22
23
24
25
EXBOX.AES Manual - Version 2.0
3 2 1
Signal digital
CH 4 OUT −
CH 3 OUT +
GND
CH 2 OUT −
CH 1 OUT +
GND
CH 4 IN −
CH 3 IN +
GND
CH 2 IN −
CH 1 IN +
GND
