MADI Port SC optical
• 1 or 2 x SC socket FDDI (input / output)
• ISO/IEC 9314-3
• Wave length 1310 nm
• Multi-Mode 62.5/125 or 50/125
AES3 Port (I/O)
• 2 x DSUB-25, female, AES59 compliant
(8 x AES3 input / output each)
• AES3 balanced, 110 Ω
Sample Rate
• 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz ± 12.5 %
MADI Format (I/O)
• 48k Frame, 96k Frame
• 56 channel, 64 channel
• S/MUX 2/4
RS 232
• 1 x DSUB-9 socket, male
• baud rates: 9600, 19200, 38400, 115200 baud
• format: 8 data bits, no parity, 1 stop bit
USB Port
• USB 2.0, type Mini B
