LED
page 38 of 60
Settings
Code
9k6 = ON
19k2 = OFF
38k4 = OFF
115k2 = OFF
9k6 = OFF
19k2 = ON
38k4 = OFF
115k2 = OFF
9k6 = OFF
19k2 = OFF
38k4 = ON
115k2 = OFF
9k6 = OFF
19k2 = OFF
38k4 = OFF
115k2 = ON
9k6 = OFF
19k2 = ON
38k4 = OFF
115k2 = ON
9k6 = OFF
19k2 = OFF
38k4 = OFF
115k2 = OFF
CHAPTER 4: Operation
Mode
active @ 9600 baud
(8, n, 1)
active @ 19200 baud
(8, n, 1)
active @ 38400 baud
(8, n, 1)
active @ 115200 baud
(8, n, 1)
inactive,
bit-transparent pass-through of
the MADI input signal to the
MADI output.
inactive,
user bits of AES input signals
replace the user bits of the
routed channels of the MADI
output signal.
