CHAPTER 4: Operation
Routing
16 audio channels can be converted between AES
and MADI. The routing of the audio signals can be
adjusted in the system menu - see page 45.
The remaining MADI channels will pass the device
unaltered. Both MADI outputs work in parallel.
NOTE
MADI @ 2 FS = 32 channels,
MADI @ 4 FS = 16 channels
If the selected routing does not fi t the chosen scaling
factor - due to the reduced number of audio channels
- the corresponding LED will blink.
page 34 of 60
EXBOX.AES Manual - Version 2.0
