Four LEDs are used to indicate the signal routing
based on a scaling factor of 1 FS.
LED
EXBOX.AES Manual - Version 2.0
Code Routing
1.. = ON
AES IN
17 .. = OFF
AES OUT < MADI IN
33.. = OFF
49.. = OFF
1.. = OFF
AES IN
17 .. = ON
AES OUT < MADI IN
33.. = OFF
49.. = OFF
1.. = OFF
AES IN
17 .. = OFF
AES OUT < MADI IN
33.. = ON
49.. = OFF
1.. = OFF
AES IN
17 .. = OFF
AES OUT < MADI IN
33.. = OFF
49.. = ON
CHAPTER 4: Operation
> MADI OUT 01-16
> MADI OUT 17-32
> MADI OUT 33-48
> MADI OUT 49-64
01-16
17-32
33-48
49-64
