MADI Bypass
A bypass mode allows to daisy-chain several devices
without altering the MADI output.
Code
1.. = OFF
17 .. = ON
33.. = ON
49.. = ON
1.. = ON
17 .. = OFF
33.. = ON
49.. = ON
1.. = ON
17 .. = ON
33.. = OFF
49.. = ON
1.. = ON
17 .. = ON
33.. = ON
49.. = OFF
CHAPTER 4: Operation
Routing
MADI IN = MADI OUT
AES OUT < MADI IN
MADI IN = MADI OUT
AES OUT < MADI IN
MADI IN = MADI OUT
AES OUT < MADI IN
MADI IN = MADI OUT
AES OUT < MADI IN
EXBOX.AES Manual - Version 2.0
01-16
17-32
33-48
49-64
