Connect the AES and serial signals to the
device:
AES3
in/out – DSUB-25 connectors
RS 232 in/out – DSUB-9 connector
NOTE
Ensure to use appropriate cabling. To link two serial
devices a cross patched cable (so called 'null-modem
cable') may be required.
5.
Connect signal cable(s) for the MADI signals.
EXBOX.AES Manual - Version 2.0
Chapter 3: Installation
page 21 of 60
